Automation 2000 manufactures a line of protection relays monitoring gas discharge (or drop of the dielectric level), pressure and temperature inside the tank of oil-filled transformers. These protection relays come with a wide array of options and accessories addressing most issues.

DGPT2

Common Integrated Safety Device

DETECTION Gas discharge or drop of the dielectric level (1 contact) Internal pressure (1 contact) Dielectric temperature (2 contacts) READING Dielectric temperature Dielectric level or gas volume OPTIONS 2 synchronous gas contacts (2G) 2 gas contacts with an offset.

DETECTION

​

  • Gas discharge or drop of the dielectric level (1 contact)

  • Internal pressure (1 contact)

  • Dielectric temperature (2 contacts)



READING

​

  • Dielectric temperature

  • Dielectric level or gas volume



OPTIONS

​

  • 2 synchronous gas contacts (2G)

  • 2 gas contacts with an offset (2GD)

  • 2 synchronous pressure contacts (2P)

  • 2 pressure contacts with an offset (2PD)

  • 80°C PTC thermistor (PTC)

  • Connection for conservator (IB)

  • Industrial and marine atmosphere (X)

  • Industrial connector (CE)

  • Marine cable gland (PA)

  • Pt100 sensor (PT)


Download the catalogue

Oil Immersed Transformer Protection

Automation 2000 is the inventor and sole manufacturer of the DGPT2®, the reference in protection relays for electrical transformers certified ISO 9001 version 2008.

DGPT2® conforms to NF EN 50216-1, NF EN 50216-3, NF EN 60529 et NF C52-107 Standards.

​

Get in touch with us for any project related assistance
